Pre-engineered hangars

The price for the complete building

from .... /m2 without VAT

Related industries: Car showroom, Factory

General:

Brand:

PK VESTA
Country/Origin of Goods:

Russia
Place of production:

Tula, Russia
FEA code:

9406903908
Supply of building kits:

Eurasia, Africa, Middle East, Latin America
Condition of buildings:

made "to order" from scratch (new)
Delivery :

land and/or sea (euro trucks and 40ft containers)
Structural warranty:

at least 50 years old
Product warranty:

1 to 5 years
Series:

INDI (Customized on order), TYP Series (Standard after project)
Scheme and form of payment:

40%x30%x30% and 70%x30% (L/C - letter of credit, T/T - bank transfer, D/P - payment after receiving a document confirming the shipment of goods by the seller)
Delivery conditions:

EXW, FOB, CIP, DAF, DDP

Load-bearing structures

Frame technologies:

LGF (cold-formed galvanized profiles), Rigid Framing (ferrous metal welded I beams) and HYBRID systems (LGF + Rigid Framing)
Element type:

H Beams (I-Beam), C Trusses/Columns (C-Channel)
Roof type:

Gable, single-slope, extensions, superstructures and flat roofs (single-span and multi-span)
Accessories:

All high-strength bolts (except anchor bolts), full trimming package, diagonal ties and connecting elements are included. Gates, doors, windows, skylights, canopies, transparent panels, solar panels
Steel type:

С245, С350, С345, C390 and C420
Galvanizing class:

only I (275 g/m2)
Metal Suppliers:

Russian Novolipetsk Iron and Steel Works and SeverStal
Secondary Elements:

Diagonal connections, secondary framing system (C-shaped, W- shaped. and Z- shaped)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)
Connection of elements:

Only 100% bolted-together connection design (high strength and normal strength bolts)
Protection of ferrous metal elements:

Powder coating and/or hot dip galvanizing
Accounting for client technology:

Included if needed

Enclosing structures

Sheathing:

sandwich panels (mineral wool, polystyrene and PIR), sheet-by-element assembly (mineral wool), corrugated sheet (cold version), ventilated facades (metal cassettes, composite cassettes and porcelain stoneware – based on the mineral wool) and membrane roof
Accessories:

trimming package (flashing, framing openings, etc.), fasteners (self-tapping screws), skylights (or transparent panels), ventilation, sectional / swing gates, double-glazed windows (up to 6 chambers), solar panels and awnings.
Thermal circuit:

internal (panels from inside the frame are mounted) or external (all panels are mounted from the outside)
Basic colors (RAL):

White (9003), Gray (7004), Blue (5005), White-Aluminum (9006), Beige (1014), Yellow (1018), Green (6002), Light Gray (9002), Brown (8017)
Mineral wool density:

not less than 100 kg/cu.m.
Sheet thickness:

0.5mm, 0.6mm, 0.7mm, 0.8mm and 1mm (galvanized)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)

Projects and Documents

Nordic Base Loads:

Snow (from 180 kg/sq.m. and above), Wind (from 32 kg/sq.m. and above) and Seismic – 6 points (MSK) Technological load: from 20 kg/sq.m. and higher.
Base loads for southern countries:

Snow (not taken into account), Wind (from 48 kg / sq.m. and above) and Seismic - 7 points and above (Richter Scale) Technological load: from 20 kg / sq.m. and higher.
Main projects:

assembly diagrams and instructions, diagrams of columns for the foundation, structure project (metal structures), cladding project (facade solutions), technical passport. Taking into account the state or commercial expertise.
Degree of fire resistance of the building:

IV-I
Certification:

ISO
Disclaimer:

when exporting buildings to other countries, different building codes are taken into account (European, American) and any other at the place of construction (Middle East, Africa, Asia, Latin America, etc.)

Making an I-shaped (H) welded beam

Metal cutting:

into strips of the desired length on a powerful high-precision laser machine
Assembly:

workpieces on the base
Welding:

all main elements
Process:

straightening elements on the mill
Partial welding:

bases of columns and stiffeners
Final preparation:

sand blasting / shot blasting / hot dip galvanizing
Painting:

included (upon request)
Factory primer:

included (20, 40, 60, 80, 100 microns and above)
Package:

in packs for euro trucks or 40 feet for containers

Making a C-profile

Process:

cold-formed metal profiling
Cutting and punching holes:

included (in auto mode)
Painting:

not included (high anti-corrosion properties)
Package:

in packs for euro trucks or 40 feet for containers

PK VESTA performs turnkey construction of hangars made out of Rigid Framing and LSF in Africa, the Middle East, Eurasia and Latin America. We offer solutions for commercial, industrial, agricultural enterprises, which allow saving on construction and erecting buildings of any complexity within 1-3 months. PK VESTA is a manufacturer, our buildings are distinguished by reliability, durability and strength. We offer the construction of hangars from sandwich panels at competitive prices.

Construction of prefabricated warehouse hangars

In recent years, there has been an increase in demand for low-cost warm and cold hangars, hangars, warehouses necessary for doing business. Modern technologies make it possible to build reliable inexpensive steel buildings in the shortest possible time.

Building hangars from sandwich panels is often cheaper than buying or renting a prefabricated building. Hangars from Rigid Framing and LSF are ordered for the needs of trade, industrial, agricultural enterprises.

The technology of prefabricated construction allows erecting turnkey hangars from metal structures in just a few months, saving 30-50% of the budget on construction.

Due to this, steel buildings are in demand not only by small businesses, but also by large industrial enterprises. To date, no type of traditional brick or reinforced concrete construction can be compared with the construction of buildings from LSF in terms of speed with similar indicators of strength and reliability.

PK Vesta has its own production facilities, the plant produces metal structures for fast and affordable construction of hangars and warehouses of various levels of complexity and purpose.

Types of hangars

Prefabricated hangars can be capital, i.e. built for a long time in accordance with building codes or temporary. The steel buildings can be used in both cases, since, if necessary, they are disassembled and assembled without losing the technological properties of materials.

According to the type of roof, the hangars are divided into single-pitched, double-pitched, hangars with a flat roof.

There are frameless and frame hangars. Frame hangars are not limited in shape and size. Frameless have an arched shape, are made of metal sheets.

The following types of hangars are classified according to the scope of application:

athletic facilities;
granaries;
car dealerships;
facilities for storage and repair of equipment;
logistics complexes, warehouses;
vegetable stores, fruit stores;
livestock complexes;
car washes;
car services (SRT)
commercial buildings;
industrial buildings.

Rigid Framing and LSF technology has been tested in different countries, it has proved its worth: buildings have been tested for durability for decades. Light metal structures are currently being actively erected throughout Russia.

PK Vesta develops and improves construction methods. The main material for LMK is hot-rolled carbon steel. For the formation of metal structures, I-beams, channels, angles, square and round pipe profiles are used.

Hangars are designed in accordance with building rules and regulations, and the necessary engineering networks are connected to them. Buildings are built for a long time or for a certain period. Temporary buildings are collapsible, if necessary, they are dismantled without loss of technological materials. Such steel buildings can be moved to another location and reassembled.

Features of prefabricated structures

The construction of hangars with all communications from sandwich panels or a metal profile is carried out from ready-made modules that are manufactured in the factory. The structure, created on the basis of a metal frame, is built at any time of the year for several months, depending on the size and complexity of the architectural solution. Buildings are insulated if necessary. Install building on a temporary base or a permanent foundation.

Installation of a block-modular building provides for the joining of elements, sealing of seams. For the reliability of the building structure, flashings are installed. Installation work does not require large labor costs, the involvement of heavy special equipment. After the erection of the steel frame, wall materials and external metal structures are treated with flame retardants.

PK VESTA employs a team of experienced installers with the necessary permits. The team goes to the site under the guidance of an engineer.

Specialists are ready to develop an individual project of any type of hangars in accordance with general construction standards, requirements for structures within the allocated budget.

Stages of building a hangar from sandwich panels

The process of building prefabricated turnkey hangars:

The construction process of the steel building begins with the development of the project;
Then proceed to the manufacture of structural elements;
In parallel, excavation and preparatory work is underway at the facility;
Engineering communications are being laid;
Prefabricated hangars with a metal frame (LSFor Rigid Framing) from the manufacturer are delivered to the prepared construction site after laying the foundation;
After assembly, the frame is sheathed with wall modules;
A roof or insulated roofing pie is mounted;
In the finished building, partitions, protective fences, gates are installed;
Before delivery, a communication check is carried out.

Our company performs turnkey works, from project development to installation and after-sales service.

Benefits of steel structure hangars

Metal hangars are light, they do not need a strong foundation. They are installed even on soil with low bearing capacity. There is no need to additionally finish the room, facing is carried out only at the request of the customer. Designs are valued for a number of advantages:

low price;
ease of installation;
construction can be carried out all year round, not only in the summer season;
assembly speed, the construction of complex complexes takes no more than 3 months;
mobility, the structure can be disassembled and moved to another place;
high strength characteristics, it is possible to build a steel building in seismically active areas;
energy efficiency, saving on heating;
resistance to atmospheric and intergranular corrosion;
long service life (at least 35 years).

The owners of the facility under construction can quickly put it into operation and make a profit.

Sandwich panel hangar calculator

You can quickly calculate the cost of a sandwich panel hangar using a special online calculator that will calculate based on your initial data. To calculate the cost of building an object, use the WebSteel® service on our website. It allows you to carry out calculations, visualize the building, create sketches and order the delivery of steel building to anywhere in the world.

Buy a prefabricated hangar from PK Vesta

The WebSteel® service will help you design a pre-fabricated hangar without special preparation, the price per m2 of construction will depend on the type of rolled metal used. By changing the initial data, using an online calculator, it is easy to choose the best steel building option. It is convenient to immediately visualize the future building, think over the layout. The program was created on the basis of ready-made projects, in which adjustments are made taking into account the parameters, design, purpose of the object.

PK VESTA is an expert in the construction of hangars from turnkey sandwich panels. We offer the construction of hangars of any complexity and size for various purposes.

To buy a turnkey pre-fabricated hangar or make a hangar according to your project, place an order on the website or contact our phone managers.
