Pre-engineered fish farms

The price for the complete building

from .... /m2 without VAT

Related industries: Electrical equipment storage, Townhouses

General:

Brand:

PK VESTA
Country/Origin of Goods:

Russia
Place of production:

Tula, Russia
FEA code:

9406903908
Supply of building kits:

Eurasia, Africa, Middle East, Latin America
Condition of buildings:

made "to order" from scratch (new)
Delivery :

land and/or sea (euro trucks and 40ft containers)
Structural warranty:

at least 50 years old
Product warranty:

1 to 5 years
Series:

INDI (Customized on order), TYP Series (Standard after project)
Scheme and form of payment:

40%x30%x30% and 70%x30% (L/C - letter of credit, T/T - bank transfer, D/P - payment after receiving a document confirming the shipment of goods by the seller)
Delivery conditions:

EXW, FOB, CIP, DAF, DDP

Load-bearing structures

Frame technologies:

LGF (cold-formed galvanized profiles), Rigid Framing (ferrous metal welded I beams) and HYBRID systems (LGF + Rigid Framing)
Element type:

H Beams (I-Beam), C Trusses/Columns (C-Channel)
Roof type:

Gable, single-slope, extensions, superstructures and flat roofs (single-span and multi-span)
Accessories:

All high-strength bolts (except anchor bolts), full trimming package, diagonal ties and connecting elements are included. Gates, doors, windows, skylights, canopies, transparent panels, solar panels
Steel type:

С245, С350, С345, C390 and C420
Galvanizing class:

only I (275 g/m2)
Metal Suppliers:

Russian Novolipetsk Iron and Steel Works and SeverStal
Secondary Elements:

Diagonal connections, secondary framing system (C-shaped, W- shaped. and Z- shaped)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)
Connection of elements:

Only 100% bolted-together connection design (high strength and normal strength bolts)
Protection of ferrous metal elements:

Powder coating and/or hot dip galvanizing
Accounting for client technology:

Included if needed

Enclosing structures

Sheathing:

sandwich panels (mineral wool, polystyrene and PIR), sheet-by-element assembly (mineral wool), corrugated sheet (cold version), ventilated facades (metal cassettes, composite cassettes and porcelain stoneware – based on the mineral wool) and membrane roof
Accessories:

trimming package (flashing, framing openings, etc.), fasteners (self-tapping screws), skylights (or transparent panels), ventilation, sectional / swing gates, double-glazed windows (up to 6 chambers), solar panels and awnings.
Thermal circuit:

internal (panels from inside the frame are mounted) or external (all panels are mounted from the outside)
Basic colors (RAL):

White (9003), Gray (7004), Blue (5005), White-Aluminum (9006), Beige (1014), Yellow (1018), Green (6002), Light Gray (9002), Brown (8017)
Mineral wool density:

not less than 100 kg/cu.m.
Sheet thickness:

0.5mm, 0.6mm, 0.7mm, 0.8mm and 1mm (galvanized)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)

Projects and Documents

Nordic Base Loads:

Snow (from 180 kg/sq.m. and above), Wind (from 32 kg/sq.m. and above) and Seismic – 6 points (MSK) Technological load: from 20 kg/sq.m. and higher.
Base loads for southern countries:

Snow (not taken into account), Wind (from 48 kg / sq.m. and above) and Seismic - 7 points and above (Richter Scale) Technological load: from 20 kg / sq.m. and higher.
Main projects:

assembly diagrams and instructions, diagrams of columns for the foundation, structure project (metal structures), cladding project (facade solutions), technical passport. Taking into account the state or commercial expertise.
Degree of fire resistance of the building:

IV-I
Certification:

ISO
Disclaimer:

when exporting buildings to other countries, different building codes are taken into account (European, American) and any other at the place of construction (Middle East, Africa, Asia, Latin America, etc.)

Making an I-shaped (H) welded beam

Metal cutting:

into strips of the desired length on a powerful high-precision laser machine
Assembly:

workpieces on the base
Welding:

all main elements
Process:

straightening elements on the mill
Partial welding:

bases of columns and stiffeners
Final preparation:

sand blasting / shot blasting / hot dip galvanizing
Painting:

included (upon request)
Factory primer:

included (20, 40, 60, 80, 100 microns and above)
Package:

in packs for euro trucks or 40 feet for containers

Making a C-profile

Process:

cold-formed metal profiling
Cutting and punching holes:

included (in auto mode)
Painting:

not included (high anti-corrosion properties)
Package:

in packs for euro trucks or 40 feet for containers

PK VESTA carries out the construction of fish farms of any type based on both Rigid Framing and LSF technologies. We offer solutions that allow you to build an object of any complexity with minimal investment. We build reliable, durable, functional turnkey steel buildings, we carry out a full range of works, from design to commissioning. Here you can choose a standard solution or order an individual project.

Turnkey fish farm

Modern fish farms are located near settlements, in some cases - within the city. This allows you to open a farm in a zone of high demand for products and sell fish at retail, and not rent it to supermarkets 2 times cheaper.

It is important to design the farm correctly, to clearly comply with the requirements for the construction of such facilities, so that the business is efficient. It is not recommended to choose a place near residential buildings and plantations. It is necessary to take into account the type of soil, since it will be necessary to dig a pit of a certain size.

It is recommended to order the turnkey construction of a farm from one contractor. Our company has an impeccable reputation, performs a full range of works, from design to after-sales service.

Design and stages

Turnkey design of fish farms implies the development of a project in accordance with SNiP. The project is the basis on which the construction is carried out.

When designing, it is necessary to take into account:

the planned capacity of the farm;
climatic features;
the design of reservoirs;
water treatment technology;
equipment to be used.

It is necessary to take into account the specifics of the object. If the fish farm will always have personnel, appropriate conditions must be created for it (bathrooms, a place for food, rest, administration offices, etc.). It is also necessary to provide a storage room, areas for equipment placement, equip access roads, places for loading fish, unloading raw materials and materials.

When designing, special attention is paid to environmental issues and environmental protection. If fish are grown in artificial ponds or pools, they must be equipped with a water purification system.

The construction of fish farms from reinforced concrete structures is not economically feasible. Today, prefabricated buildings based on both Rigid Framing and LSF technologies are used, which are cheaper, but are distinguished by high strength, durability and resistance to corrosion. In addition, they have high insulating characteristics, which reduces the cost of creating an optimal microclimate.

Construction of a mini fish farm

PK VESTA offers effective business solutions based on LSF technologies. We build inexpensive and functional buildings of varying complexity and purpose. If you are planning to open a fish farm, we will offer you a standard project or develop an individual one, taking into account the specifics of future facilities and budget.

Steel buildings are made of high quality galvanized profiles. To increase energy efficiency, they are sheathed with sandwich panels. Structures are manufactured in accordance with the project at our production facilities, after which they are delivered to the site and assembled. We are a manufacturer, we offer a turnkey fish farm price lower than that of competitors.

Our company performs a full range of works, from design to commissioning. The WebSteel® service is implemented on the PK VESTA website, with the help of which customers not only from Russia, but also from any corner of the world can determine the cost of steel building, make other calculations and visualize the object.

To order a prefabricated fish farm or get advice, fill out the form on the website or contact our phone managers.

Make an inquiry Price a building online

Fish farming is a profitable business that requires impressive investments at the stage of its creation. The use of prefabricated structures will help to avoid serious costs and start the operation of a fish farm in the shortest possible time.

The construction of LSGF has already been tested by time and has a number of significant advantages:

· Installation of a metal frame does not require a buried foundation.

· The technology of "dry" construction allows you to do without mixing concrete and hardening.

· Construction from LSGF does not imply the use of bulky special equipment (truck cranes, excavators) at the facility.

· Installation of prefabricated buildings is possible at any time of the year.

· Buildings from LSGF do not deform over time, do not require certain temperature conditions at the construction stage, and do not go through the shrinkage stage.

· Finished buildings are seismic and fire resistant, do not corrode, do not rust over time, their bearing capacity does not decrease.

· From the beginning of construction to the stage of finishing work at the facility, only a few weeks pass.

PK VESTA company offers a full range of services for the construction of fish farms: from the departure to the facility and measurement, finishing with the finishing of the building from the inside according to a predefined work schedule. To save your money and working time, we offer ready-made projects - our experts have extensive experience in the construction of turnkey fish farms, so we will calculate the optimal size of the structure, select the appropriate finishing materials and insulation, provide the opportunity to place all the necessary equipment inside the finished hangar.

Construction of fish farms in Russia and the CIS

Our company has extensive experience in the construction of household and utility buildings for various purposes. These are warehouse complexes, shops, swimming pools, sports centers, car services, manufacturing enterprises, livestock farms.

Among the projects we have implemented are compact but reliable facilities for growing fish in artificial conditions. The turnkey fish farm, designed and implemented by experts, will be distinguished by endurance and durability, and high-quality insulation material will allow to maintain the desired temperature in the premises. The use of galvanized metal profiles as the basis of the building allows you to start construction on any construction site. The building area does not require additional training. And after the construction is completed, there is no waste and unnecessary building materials left.

You can calculate the price of a turnkey fish farm yourself on the site or with the help of our manager. Pre-select the region where you plan to build the farm. The geography of our activity is very extensive - we work in almost all regions of Russia and the CIS countries.

Choosing PK VESTA you will receive:

1. The new philosophy and innovative business model of the “Smart Techno Design” allowing a client to quickly visualize pre-engineered steel buildings online in new service WebSteel, calculate main building costs instantly with automatic consideration of climatic zones (snow, wind and seismic), receive basic sketches with a detailed technical specification and order a turnkey building kit online from the factory to anywhere in the world.
2. Unique building solutions from an old factory in the famous Russian industrial city of Tula (metal craftsman
