General:

Brand:

PK VESTA
Country/Origin of Goods:

Russia
Place of production:

Tula, Russia
FEA code:

9406903908
Supply of building kits:

Eurasia, Africa, Middle East, Latin America
Condition of buildings:

made "to order" from scratch (new)
Delivery :

land and/or sea (euro trucks and 40ft containers)
Structural warranty:

at least 50 years old
Product warranty:

1 to 5 years
Series:

INDI (Customized on order), TYP Series (Standard after project)
Scheme and form of payment:

40%x30%x30% and 70%x30% (L/C - letter of credit, T/T - bank transfer, D/P - payment after receiving a document confirming the shipment of goods by the seller)
Delivery conditions:

EXW, FOB, CIP, DAF, DDP

Load-bearing structures

Frame technologies:

LGF (cold-formed galvanized profiles), Rigid Framing (ferrous metal welded I beams) and HYBRID systems (LGF + Rigid Framing)
Element type:

H Beams (I-Beam), C Trusses/Columns (C-Channel)
Roof type:

Gable, single-slope, extensions, superstructures and flat roofs (single-span and multi-span)
Accessories:

All high-strength bolts (except anchor bolts), full trimming package, diagonal ties and connecting elements are included. Gates, doors, windows, skylights, canopies, transparent panels, solar panels
Steel type:

С245, С350, С345, C390 and C420
Galvanizing class:

only I (275 g/m2)
Metal Suppliers:

Russian Novolipetsk Iron and Steel Works and SeverStal
Secondary Elements:

Diagonal connections, secondary framing system (C-shaped, W- shaped. and Z- shaped)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)
Connection of elements:

Only 100% bolted-together connection design (high strength and normal strength bolts)
Protection of ferrous metal elements:

Powder coating and/or hot dip galvanizing
Accounting for client technology:

Included if needed

Enclosing structures

Sheathing:

sandwich panels (mineral wool, polystyrene and PIR), sheet-by-element assembly (mineral wool), corrugated sheet (cold version), ventilated facades (metal cassettes, composite cassettes and porcelain stoneware – based on the mineral wool) and membrane roof
Accessories:

trimming package (flashing, framing openings, etc.), fasteners (self-tapping screws), skylights (or transparent panels), ventilation, sectional / swing gates, double-glazed windows (up to 6 chambers), solar panels and awnings.
Thermal circuit:

internal (panels from inside the frame are mounted) or external (all panels are mounted from the outside)
Basic colors (RAL):

White (9003), Gray (7004), Blue (5005), White-Aluminum (9006), Beige (1014), Yellow (1018), Green (6002), Light Gray (9002), Brown (8017)
Mineral wool density:

not less than 100 kg/cu.m.
Sheet thickness:

0.5mm, 0.6mm, 0.7mm, 0.8mm and 1mm (galvanized)
Preparation level of elements:

High (numbering of elements taking into account cutting to the desired length, punching holes and a packing list for quickly finding the right pack at the construction site)

Projects and Documents

Nordic Base Loads:

Snow (from 180 kg/sq.m. and above), Wind (from 32 kg/sq.m. and above) and Seismic – 6 points (MSK) Technological load: from 20 kg/sq.m. and higher.
Base loads for southern countries:

Snow (not taken into account), Wind (from 48 kg / sq.m. and above) and Seismic - 7 points and above (Richter Scale) Technological load: from 20 kg / sq.m. and higher.
Main projects:

assembly diagrams and instructions, diagrams of columns for the foundation, structure project (metal structures), cladding project (facade solutions), technical passport. Taking into account the state or commercial expertise.
Degree of fire resistance of the building:

IV-I
Certification:

ISO
Disclaimer:

when exporting buildings to other countries, different building codes are taken into account (European, American) and any other at the place of construction (Middle East, Africa, Asia, Latin America, etc.)

Making an I-shaped (H) welded beam

Metal cutting:

into strips of the desired length on a powerful high-precision laser machine
Assembly:

workpieces on the base
Welding:

all main elements
Process:

straightening elements on the mill
Partial welding:

bases of columns and stiffeners
Final preparation:

sand blasting / shot blasting / hot dip galvanizing
Painting:

included (upon request)
Factory primer:

included (20, 40, 60, 80, 100 microns and above)
Package:

in packs for euro trucks or 40 feet for containers

Making a C-profile

Process:

cold-formed metal profiling
Cutting and punching holes:

included (in auto mode)
Painting:

not included (high anti-corrosion properties)
Package:

in packs for euro trucks or 40 feet for containers

PK VESTA carries out the construction of prefabricated steel buildings of any complexity and purpose using modern light-weighted construction technologies. We have many years of experience in the construction of track and field arenas and other sports facilities. We build reliable, aesthetic, durable buildings in accordance with construction requirements, sanitary and hygienic standards and sports standards. We develop individual projects, taking into account the specifics of the future facility, regional and climatic features, the customer's budget and other factors.

Construction of an athletics arena stages

The construction of sports arenas made out of LSF takes on average several months, depending on the complexity of the facility. Construction can be carried out at any time of the year.

Construction stages:

Object design.
Production of structures.
Delivery of structures to the construction site.
Raising the frame.
Cladding with sandwich panels.
Installation of windows, walls, partitions, roofs and other elements.
Installation of engineering systems.
Delivery of the object.

Arenas for light and weightlifting

Indoor sports arenas made out of Rigid Framing and LSF are designed for light and weightlifting all year round. Most of them are built taking into account not only training, but also competitions of different levels. Therefore, in such complexes, stands for spectators are provided.

The standard complex, in addition to the arena itself, includes locker rooms, showers, methodological rooms, administrative, utility rooms, a conference room, a cafe, etc. can be provided.

Sports grounds are located on the ground floor; for the athletics arena, a running track should be equipped around the perimeter. When designing, the type of sports equipment used, its attachment to the floor, walls, stream (rings, bars, ropes, horizontal bars, etc.) are taken into account. Free space must be provided between sports equipment. On the weightlifting site, you need to take into account the high impact loads on the floor when the bar falls.

Construction features

During the construction of an athletics arena in Togliatti, first of all, a frame is constructed from light metal structures that were made specifically for this facility in accordance with the project. Then the floor is poured, the building is sheathed with sandwich panels, windows, doors, internal partitions are installed, the roof is mounted. The final stage is the installation of engineering systems.

For the construction of sports complexes, durable ones are used. rigid frames made of I-beams or welded pipes. More often, a combined design is used - ferrous metal columns made of I-beams and a farm covering made of a bent profile. The profile does not need additional anti-corrosion protection, it has high strength.

Columns are mounted from a height of 7 meters, the step of the columns is 6 meters. During construction, exclusively bolted connection is used. Finishing can be made of sandwich panels made of painted or galvanized steel.

It is possible to order a project with adaptation to a certain climatic zone all over the world. The overall dimensions of areas for light and weightlifting, the basic requirements for them, are regulated by the norms for planning elements of residential and public buildings and other regulatory documents.

The complexes are equipped with heating, ventilation, water supply, sanitation and other necessary communications. Skylights should provide sufficient natural light. Fluorescent lamps are mainly used as artificial lighting. Supply and exhaust systems are used to supply fresh air, which are connected to the upper zone of the facility.

Our sports complexes have a number of advantages:

metal structures and cladding will last at least 30 years even in harsh climates;
the cost of construction and maintenance of the pre-engineered steel buildings is much lower than that of a capital building;
compliance with all hygienic and fire safety standards of construction;
safety for people and the environment;
the possibility of developing a non-standard project.

Contact PK VESTA, our company performs a full range of works on the construction of steel buildings, from design to installation, gives a guarantee. With the help of a special WebSteel® service posted on the website, you can design a sports rental for free online, calculate its cost and place an order 24/7 anywhere in the world.

Make an inquiry Price a building online

It is mounted from light steel structures - galvanized profile of our production. In terms of performance, such a profile is not inferior to structures made of ferrous metal, but has a significantly lower weight. For the construction of the "Cayman" in most cases, heavy lifting equipment is not needed: a manipulator is enough.

Choosing PK VESTA you will receive:

1.   The new philosophy and innovative business model of the “Smart Techno Design” allowing a client to quickly visualize pre-engineered steel buildings online in new service WebSteel, calculate main building costs instantly with automatic consideration of climatic zones (snow, wind and seismic), receive basic sketches with a detailed technical specification and order a turnkey building kit online from the factory to anywhere in the world.
2.   Unique building solutions from an old factory in the famous Russian industrial city of Tula (metal craftsmanship since the 17th century) offered specifically for you to design and manufacture energy-efficient custom prefabricated steel buildings made out of lightweight metal structures.
3.   Particular emphasis on the quality of our products, the high safety and reliability of our production facilities with the high automation of working processes and the latest IT technologies in the 24/7 format of customer service via the Internet in global markets (Eurasia, Africa, the Middle East and Latin America)

Technology comparison:

List	LSGF (profiles)	Rigid framing (welded beams)	Concrete

1) Metal consumption of Steel framing	Low	Medium	High
2) Load-bearing capacity	High	High	High
3) Complexity of manufacturing	Low	Medium	Medium

4) Complexity of erection	Low	Medium	Medium
5) Anticorrosion properties	High	Low	Low
6) Foundation costs	Low	Medium	High

7) Capacity in one vehicle	High	Medium	Low
8) Welding process	Missing	Available	Missing
9) Level of
